☆ 24 VAC/DC Excitation ☆ Excellent Long Term Stability ☆ Easy to Install ☆ Voltage or 4-20mA two wire output
The 5266 low range pressure transmitter measures gauge or differential pressure by means of a stainless steel diaphragm, and capacitive sensor. The model 5266 incorporates an ASIC to provide a temperature compensated high level analogue out put over the temperature range -18 to +65°C. Mounted in a glass filled polyester case with pipe fittings the 5266 can measure pressures in the range 100 - 5000 pascals.
The micro-tig welded tension sensor allows up to 69kPa overpressure (in either direction) with no damage to the unit. In addition, the sensor parts have thermally matched coefficients, which promote improved temperature performance and excellent long-term stability
